Specifications
Maximum Polyphony 4 voice
LFO Waveform (SINE, TRIANGLE, SAW, SQUARE, Sample&Hold, Random)
Fade Time
Rate
Pitch Modulation Level
Filter Modulation Level
Amplifier Modulation Level
Oscilator Wave Form (SAW, SQUARE, TRIANGLE, SAW 2, SQUARE 2, TRIANGLE 2, NOISE SAW, LOGIC OPERATION, FM, FM+SYNC, VOWEL, CB)
Sub Oscillator (-1 Oct, -2 Oct)
Noise Oscillator (White Noise, Pink Noise)
Range (64, 32, 16, 8, 4, 2)
Color
Fine Tune
Coarse Tune
Oscillator Sync
Cross Modulator
Ring Modulator
Modulation Source (MANUAL, LFO, P. ENV, F. ENV, A. ENV, SUB OSC)
Envelope Attack Time
Envelope Decay Time
Envelope Depth
Mixer OSC 1
OSC 2
SUB OSC
NOISE
Filter LPF Type (-12 dB, -24 dB)
LPF Cutoff
Resonance
HPF Cutoff
Envelope Attack Time
Envelope Decay Time
Envelope Sustain Level
Envelope Release Time
Envelope Depth
Key Follow
Amplifier Envelope Attack Time
Envelope Decay Time
Envelope Sustain Level
Envelope Release Time
Effect Tone
Crusher
Reverb
Delay
Delay Time
Arpeggio Arpeggio Switch
Arpeggio Type (1 Oct Up, 1 Oct U+D, 1 Oct Down, 2 Oct Down, 2 Oct U+D, 2 Oct Up)
Arpeggio Step (1/4, 1/8, 1/16, 1/4T, 1/8T, 1/16T)
Scatter Type (1–10)
Depth (1–10)
Tune 430–450 Hz
Controller Volume
Portamento
Legato switch
Bend Range
Tempo Sync switch
LFO Key Trigger switch
Key Assign Mode switch
Key Hold switch
Octave (-3, -2, -1, 0, 1, 2, 3)
Sampling Frequency 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Patches per bank 64 patches
*User can make new user banks.
Plugin-Formats VSTi 2.4 (32 bits, 64 bits) * Windows only
VSTi 3.6 (32 bits, 64 bits)
AU
System Requirements (macOS™)
Operating System macOS 10.14
macOS 10.15
macOS 11
Host Application VST instruments (VSTi) version: VST 3.6 compatible
Audio Units (AU) version: V2 Audio Units compatible AAX Compatible
CPU Intel® Core™ i5 or better, Apple silicon compatible
RAM 4 GB or more
Hard Disk 100 MB or more
Display resolution and Colors 1280 x 800 dots or higher, 16.7 million colors or more
Other You'll need Internet connectivity to activate this software.
You'll need installation SYSTEM-1 driver to plug-out this software to the SYSTEM-1.
System Requirements (Windows®)
Operating System Microsoft® Windows® 8.1 (64-bit)
Microsoft® Windows® 10 (64-bit)
*This does not work with the Windows® RT.
*This does not work with the Windows® Phone.
*This does not work on the virtual machines such as Hyper-V, Virtual PC, or Boot Camp.
Host Application VST instruments (VSTi) version: VST 2.4/3.6 compatible, AAX Compatible
CPU Intel® Core™ i5 or better
RAM 2 GB or more
Hard Disk 100 MB or more
Display resolution and Colors 1280 x 800 dots or higher, 24 bits Full Color or more
Other You'll need Internet connectivity to activate this software.
You'll need Adobe Reader (available free of charge) in order to read the online help.
You'll need installation SYSTEM-1 driver to plug-out this software to the SYSTEM-1.
