Specifications
Maximum Polyphony 1 voice
Modulator LFO Rate
Delay Time
Waveform (SIN, TRI, SAW, SQR, RANDOM(S/H))
VCO Auto Bend Depth
Modulation Depth
VCO-1 Range (64, 32, 16, 8, 4, 2)
Waveform (S...
mehr lesen
Specifications
Maximum Polyphony 1 voice
Modulator LFO Rate
Delay Time
Waveform (SIN, TRI, SAW, SQR, RANDOM(S/H))
VCO Auto Bend Depth
Modulation Depth
VCO-1 Range (64, 32, 16, 8, 4, 2)
Waveform (SAW, SQR, SIN)
Pulse Width
PWM Mode switch (MANUAL, LFO, AUTO BEND, VCF ENV, VCA ENV, VCO-1 SUB)
Bender Depth
VCO-2 Range (64, 32, 16, 8, 4, 2)
Waveform (SAW, SQR, NOISE)
Pulse Width
PWM Mode switch (MANUAL, LFO, AUTO BEND, VCF ENV, VCA ENV, VCO-1 SUB)
Fine Tune
Coarse Tune
Audio Mixer VCO-1
VCO-2
VCO-1 SUB
VCF Cutoff Frequency
Resonance
ENV Depth
Modulation Depth
Keyboard Follow
VCF ENV Attack Time
Decay Time
Sustain Level
Release Time
VCA VCA Mode (GATE, A.ENV, F.ENV, HOLD)
Tone
Crusher Depth
VCA ENV Attack Time
Decay Time
Sustain Level
Release Time
VCF/VCA ENV Gate-Trigger switch (GATE, LFO, GATE+TRIG, LFO+GATE)
Effect Reverb Level
Delay Level
Delay Time
Controller Volume
Portamento
Bend Range
Tempo Sync switch
Arpeggio Arpeggio Switch
Arpeggio Type (1 Oct Up, 1 Oct U+D, 1 Oct Down, 2 Oct Down, 2 Oct U+D, 2 Oct Down)
Arpeggio Step (1/4, 1/8, 1/16, 1/4T, 1/8T, 1/16T)
Tune 430 Hz–450 Hz
Sampling Frequency 44.1 kHz, 88.2 kHz, 176.4 kHz, 48 kHz, 96 kHz, 192 kHz
Tones per 1 bank 64 patches
* User can make new user banks.
Plug-In Formats VSTi 3.6 (32 bits, 64 bits), AU
Plug-Out Hardware SYSTEM-1
System Requirements (macOS™)
Operating System macOS 10.14
macOS 10.15
macOS 11
Host Application VST instruments (VSTi) version: VST 3.6 compatible
Audio Units (AU) version: Audio Units V2 compatible
AAX Compatible
CPU Intel® Core™ i5 or better, Apple silicon compatible
RAM 4 GB or more
Hard Disk 100 MB or more
Display resolution and Colors 1280 x 800 dots or higher, 16.7 million colors or more
Other You'll need Internet connectivity to activate this software.
You'll need installation SYSTEM-1 driver to plug-out this software to the SYSTEM-1.
System Requirements (Windows®)
Operating System Microsoft® Windows® 8.1 (64-bit)
Microsoft® Windows® 10 (64-bit)
*This does not work with the Windows® RT.
*This does not work with the Windows® Phone.
*This does not work on the virtual machines such as Hyper-V, Virtual PC, or Boot Camp.
Host Application VST instruments (VSTi) version: VST 2.4/3.6 compatible AAX Compatible
CPU Intel® Core™ i5 or better
RAM 2 GB or more
Hard Disk 100 MB or more
Display resolution and Colors 1280 x 800 dots or higher, 24 bits Full Color or more
Other You'll need Internet connectivity to activate this software.
You'll need Adobe Reader (available free of charge) in order to read the online help.
You'll need installation SYSTEM-1 driver to plug-out this software to the SYSTEM-1.
