Technische Daten
Specifications
Maximum Polyphony 8 voice
LFO Waveform (SINE, TRIANGLE, SAW, SQUARE, RND1, RND2)
Rate
Delay Time
KEY TRIGGER (ON, OFF)
TRIGGER ENVELOPE (ON, OFF)
VCO Modulation Modulation (VCO-1, BO...
mehr lesen
Specifications
Maximum Polyphony 8 voice
LFO Waveform (SINE, TRIANGLE, SAW, SQUARE, RND1, RND2)
Rate
Delay Time
KEY TRIGGER (ON, OFF)
TRIGGER ENVELOPE (ON, OFF)
VCO Modulation Modulation (VCO-1, BOTH, VCO-2)
LFO Modulation Depth
ENV-1 Modulation Depth
Pulse Width Modulation(PWM)
Pulse Width Modulation(PWM) Switch (MANUAL, LFO, ENV1+, ENV1-, ENV1+, ENV1-)
VCO-1 Waveform (SAW, PWM, TRIANGLE, SINE, SQUARE, NOISE)
Range (64', 32', 16', 8', 4', 2')
Cross Modulation
VCO-2 Waveform(SAW, PWM, TRIANGLE, SINE, SQUARE, NOISE)
Range (64', 32', 16', 8', 4', 2')
Oscillator Sync
Source Mixer VCO-1 Level
VCO-2 Level
HPF Cutoff Frequency
VCF Cutoff Frequency
Resonance
Slope (-24 dB, -18 dB, -12 dB)
ENV Modulation Depth
ENV Modulation Switch (ENV-1, ENV-2)
LFO Modulation Depth
Key Follow
Velocity Sense
VCA Level
LFO Modulation Depth
Velocity Sense
ENV-1(VCF) Attack Time
Decay Time
Sustain Level
Release Time
Key Follow (On/Off)
ENV-2 (VCF/VCA) Attack Time
Decay Time
Sustain Level
Release Time
Key Follow (On/Off)
Effect Type (OVERDRIVE, DISTORTION, METAL, FUZZ, CRUSHER, PHASER)
TONE
DEPTH
Delay/Chorus Type (DELAY, PANNING DELAY, CHORUS 1, CHORUS 2, FLANGER, DELAY + CHORUS)
TIME
LEVEL
Reverb Type (AMBIENCE, ROOM, HALL 1, HALL 2, PLATE, MODULATION)
TIME
LEVEL
Controller BEND SENS PITCH
BEND SENS FILTER
MOD SENS PITCH
MOD SENS FILTER
PORTAMENTO
LEGATO (ON, OFF)
BEND RANGE
BEND GAIN (1, 2, 3, 4)
TEMPO SYNC (ON, OFF)
KEY ASSIGN (POLY, MONO, UNISON)
KEY HOLD (ON, OFF)
OCTAVE (-3, -2, -1, 0, +1, +2, +3)
CONDITION
Arpeggio Arpeggio Mode (UP, DOWN, U&D, RND)
Arpeggio Range (1, 2, 3, 4)
Tune 430 Hz--450 Hz
Plug-Out Hardware SYSTEM-8
Plug-In Formats VSTi 2.4 (64 bits) * Windows only
VSTi 3.6 (64 bits)
AU
AAX
Sampling Frequency 44.1 kHz, 48 kHz
Patches Preset: 64
System Requirements (macOS™)
Operating System macOS 10.14
macOS 10.15
macOS 11
Host Application VST instruments (VSTi) version: VST 3.6 compatible
Audio Units (AU) version: Audio Units V2 compatible
AAX Compatible
PLUG-OUT Hardware2 SYSTEM-8
CPU Intel® Core™ i5 or better (Quad-core CPU recommended), Apple silicon compatible
RAM 4 GB or more
Hard Disk 100 MB or more
Display resolution and Colors 1280 x 800 dots or higher, 16.7 million colors or more
Other You'll need Internet connectivity to activate this software.
The SYSTEM-8 driver must be installed on your computer to connect this software to the SYSTEM-8.
System Requirements (Windows®)
Operating System1 Microsoft® Windows® 8.1 (64-bit)
Microsoft® Windows® 10 (64-bit)
*This does not work with the Windows® RT.
*This does not work with the Windows® Phone.
*This does not work on the virtual machines such as Hyper-V, Virtual PC, or Boot Camp.
Host Application VST instruments (VSTi) version: VST 2.4/3.6 compatible, AAX Compatible
PLUG-OUT Hardware2 SYSTEM-8
CPU Intel® Core™ i5 or better (Quad-core CPU recommended)
RAM 4 GB or more
Hard Disk 100 MB or more
Display resolution and Colors 1280 x 800 dots or higher, 24 bits Full Color or more
Other You'll need Internet connectivity to activate this software.
You'll need Adobe Reader (available free of charge) in order to read the online help.
The SYSTEM-8 driver must be installed on your computer to connect this software to the SYSTEM-8.
